Medical Solution

Medical Equipment and Automation

Improved patient care

About Us

During the past years, the team members of ATOM-MED have managed to establish excellent relations with a considerable number of foreign companies. This helps us to be able to supply the public and private market in Kosovo with a wide range of medical products. We supply medical equipment and laboratory products to the Ministry of Health, hospitals in Pristina, Pejë, Prizren, Gjakovë, Gjilan, Ferizaj, Vushtrri and Mitrovica, about hundreds of family medicine centers, private hospitals, private clinics, private laboratories, diagnostic centers, of radiology and so on. We have managed to create many contacts and friendships with leading doctors and managers in hospitals and private clinics throughout the territory of Kosovo.



See More

Thermo-Shaker with cooling for microtubes and PCR plates

Thermo–Shaker TS-100C provides intensive mixing and temperature control of samples in microtest tubes or PCR plate. This model of Thermo–Shaker differs from TS-100 with a possibility of cooling samples down to +4°C. Features of TS-100C meet the highest expectations of users according to many parameters:
Fast reaching of specified mixing speed and maintenance of equal amplitude of rotation throughout the Thermo–Shaker block;
Stability of maintaining the preset temperature in a wide range throughout the Thermo–Shaker’s block surface;
LCD display indicates preset and current values of temperature, speed and time of operation;
Quiet motor operation, compact size, prolonged service life.
Functions of heating and mixing can be performed both simultaneously and independently.

There are five heating and cooling blocks available, including a block with a plastic lid for the PCR-plates. All blocks are mutually interchangeable and can be easily installed on Thermo–Shaker.

The instrument is applicable in:

Genetic analysis — in extraction of DNA, RNA and further sample preparation;
Biochemical study of enzymatic reactions and processes;
Extraction of metabolites from cellular material.
Temperature Calibration Function
With the help of the temperature calibration function the user can calibrate the unit approx. ±6% of the selected temperature to compensate differences in the thermal behaviour of tubes from different manufacturers.
Specifications
Temperature setting range: +4°C ... +100°C
Temperature control range: 15°C below ambient ... +100°C
Temperature setting resolution: 0.1°C
Temperature stability: ±0.1°C
Temperature accuracy at +37°C: ±0.5°C
Average heating speed: from +25°C to +100°C 5°C/min
Average cooling speed: from +100°C to +25°C 5°C/min
Average cooling speed: from +25°C to +4°C 1.8°C/min
Temperature uniformity over the block at +4°C: ±0.6°C
Temperature uniformity over the block at +37°C: ±0.1°C
Temperature uniformity over the block at +100°C: ±0.3°C
Temperature calibration coefficient range: 0.936...1.063 (± 0.063)
Speed control range: 250–1400 rpm
Digital time setting: 1 min–96 hrs / non–stop (increment 1 min)
Timer sound signal: +
Orbit: 2 mm
Display: LCD, characters: 16 x 2
Microprocessor controlled temperature, mixing speed and running time: +
Maximum continuous operation time: 168 hours
Overall dimensions (W×D×H): 220x240x90 mm
Weight: 3.7 kg
Input current/power consumption: 12 V, 4.9 A / 60 W
External power supply:
  • Input AC 100–240 V; 50/60 Hz;
  • Output DC 12 V
  • Selectra ProXL


    Reading speed: 450 tests with ISE and 360 tests without ISE


    Number of Repositories: 64 Reagent Locations in Two Trays, Used in Cc10 – Cc25 and CC50 Bottles Equipped With Cooling System | Possibility to use any of the stations as R3-R2-R1 reagents

    Reagent sampling system and sample: Dy shiringa prej 1000 μl për grumbullimin e reagentëve dhe dy shiringa 100 μl për mbledhjen e mostrës. Vëllimi i lëvizshëm prej 400-110 μl për R1 dhe vëllimi i lëvizshëm μL 180 për R2 dhe R3 me një kapacitet vjeljeje μl 1, vëllimi i kampionit 30 μl me aftësi nxjerrjeje 0,1 μl, gjilpëra e reagentit e pajisur me një ngrohës fillestar.
    Për të parandaluar kontaminimin e reagentëve dhe mostrave, gjilpërat e recetës janë të pajisura me një sensor sipërfaqësor dhe prania e sistemit lejon zbulimin e vëllimit në shishet e referencës. Gjilpërat e reagentit dhe mostrës, përveç sensorit të sipërfaqes, janë të pajisura me një sensor përplasjeje.

    Reaction Tray (Cuvette): Me dy tabaka të veçanta reagimi, secila tabaka ka 48 kuveta ndërlidhëse, me sistem larjeje të plotë automatike.
    Sistemi i elementeve Peltier ka një temperaturë prej 37 ° C (± 0,1 ° C)

    Optical system: 12V 20V halogen bulb Two separate optical systems each have 8 optical filters with wavelengths 340 – 405 – 505 – 546 – 578 – 620 – 660 and 700 nm, each one being interchangeable.

    Photometric suffering: Linear photometric suffering -0.1-3.0 with an accuracy of 0.001Abs

    Reading methods: Ability to measure with Biochromatic End point and Kinetic Two point, End point, Ability to plot the automatic reaction dilution reaction of specific specimens (samples whose concentrations exceed the line readings of the kit). Perform a calibration of one Spot and multipoint (for tests whose curves are shaped as responses) Prozone Check for immune testing with CUT OFF functionality and compute reagent blank and sample blank calculations if necessary.

    Quality control: the ability to define 15 different controls and the possibility of placing 3 controls for a monthly quality control charts test and applying the rules of the westgard

    Standards: CB, CE-IVD dhe UL

    Computer Specifications and Software: PC with Touch Screen, Windows XP MS Software Included with RS232 Output (Network)

    Power consumption and environmental specifications and consumption of distilled water: Vac 240-100 volts and maximum power consumption VA 1K Frequency 60-50 Hz Can be used at ambient temperature 15-15 ° C and humidity 15-88% Distilled water 1 liter per hour

    Extras: (According to the order and not available with the device) Bar code reader Isolation of dilute and thick sewage | ISE for measuring Potassium-sodium-Chloride and Co2 | Printer

    Dimensions and weight of the device: length 117 cm, width 80 cm, height 115 cm, weight 190 kg

    FAN hp

    For an easy and reliable detection of Helicobacter pylori infections. The FANhp is designed for easy testing of H. pylori from bagged breath samples. For other 13C test protocols and the use of an automatic sample feeder, the well-established HeliFANplus and FANci2 range of FAN devices are recommended. FANhp was developed for physician practices, screening centers and hospitals that want to introduce 13C-urea breath testing for the detection of Helicobacter pylori infections at a reasonable cost. Simply connect the base and sample bag to the 2 ports and tap the start button on the touch screen to start the measurement. The result and diagnosis proposal will appear within 5 minutes. The result can be automatically printed from the built-in printer. For recording a daily log or a system test, the data can be downloaded to a USB and transferred to a computer. No computer required, all operations are performed via a touch screen operated with gloves. Easy to read and bright TFT display. Only four buttons on the desktop (Start, Results, Linearization, Settings), all functions created with icons → easy and direct operation in daily practice, low training requirement. Adjustable positive/negative cut-off for all H. pylori test kits on the market that can be used with bags. Connected wireless barcode scanner to import patient or test IDs. Automatic correction of negative values created by accidental inversion of the base and sample bags. If desired, results are printed immediately as soon as they are available. 300 patient results can be stored in memory, allowing data to be recorded as a daily diary by printing or exporting to a data store. Built-in self-test at the touch of a button. The device is ready for daily operation after running the "Linearization" process in the morning (10 minutes = a cup of coffee). Consumables: bags, absorbents (about 1000 samples), Nafion® tube (per year), air filter (per year) CE certified Service interface for software updates and maintenance (from the distributor). Accurate, reliable and durable: fully following the tradition of "Made in Germany" by FAN. Attractive price due to concentration of features and functions.

    IONIX – Microchip electrode without filling

    (Na+, K+, Cl-, Ca2+, pH, Li+)
    IONIX - The new Ion Selective Electrodes analyzer to create as you see fit. The IONIX is the newest addition to SFRI’s range of ion analyzers with selective electrodes. Developed and manufactured by SFRI with the best and latest technologies, the IONIX is a high quality instrument that gives excellent results.
    Create it from scratch.
    No limit, no target laboratory, the IONIX can reach anyone who does electrolytes tests. Why? Because SFRI’s analyzer is 100%-modular.
    1 IONIX – 6 OPTIONS – 48 POSSIBLE VERSIONS
    And … SFRI is currently developing a 12V battery connection that will give the IONIX the ability to work no matter where and the power stability. And with this option, it’s 80 possible versions of the IONIX that SFRI will offer!
    SFRI manufactures here, a powerful, high technological analyzer that will not only give excellent results but most of all will make everyone agree thanks to its use, its adaptability, its easiness, its friendliness and its modularity. The IONIX fits any small labs as it can fit big labs respecting the ISO 15189.
    SFRI produces here, a powerful, high-tech analyzer that will not only deliver excellent results, but above all will make everyone agree thanks to its usability, adaptability, ease, friendliness and modularity his. IONIX adapts to any small laboratory as it can adapt to large laboratories respecting ISO 15189.
    Finally there is a gem of modernity for a basic but crucial test.
    Modernity? Of course. IONIX offers all the features you expect from a new analyzer on the market: total safety, full traceability, small and compact, working in primary tubes, finally (economy and simplicity), with highly technical electrodes, easy software and friendly, modern. connection (LIS protocol), ...., definitely modern.

    Nexus IB10 Analyzer

    Point of Care Analyzer
    The Nexus IB10 is a high-quality, fast, easy-to-use point-of-care instrument for clinicians who need to make decisions in a high-stress, complex environment, providing test results in 20 minutes. The IB10 has an innovative design that makes all steps easy for the end user.
    The Nexus IB10 is an immunoanalyzer that quantitatively measures antigens or antibodies in whole blood or plasma samples on a dedicated test disc. The Nexus IB10 system combines chemistry with microfluidics and centrifugal flow to separate cell-free plasma from whole blood. The plasma is then moved through a channel, mixed with the immunoconjugates, and quantified.
    The automated testing process allows for fast and accurate test results with minimal maintenance.
    Results are reported in 20 minutes
    An intuitive user interface with minimal user interaction
    Small footprint for optimal use of space
    Built-in self-test function minimizes maintenance
    No sample preparation is required. Blood separation is done on the Nexus IB10 instrument
    Test discs stable at room temperature for up to 30 days* (*Consult individual IFU product)
    Connect to Laboratory Information Management System (LIMS)
    Built-in thermal printer
    Consumable disk
    The sphingotest ® disc combines chemistry with centrifugal microfluidic flow to rapidly prepare cell-free plasma from whole blood, which can then be flowed through a channel to rehydrate, dissolve and mix with freeze-dried immunoconjugates.
    Using a combination of active flow and capillary action, the test is ready to be quantitatively measured in 20 minutes with an optical signal level proportional to the analyte concentration.
    After adding the patient sample, the entire test is performed within the Nexus IB10 analyzer which controls disc temperature as well as sequence, measurement duration, centrifugal flow, mixing, incubation, timing, final signal measurement, quantification and reporting of results. The drive also includes an internal positive control to ensure that the test equipment has functioned properly.
    Each lot of disks is calibrated for the specific analyte to be measured to ensure lot-to-lot variability is minimized. The lot-specific calibration along with additional information such as lot expiration date is found on the QR code label attached to each disc. It is recommended that external controls also be tested at appropriate time intervals to confirm that the reagent pool is performing within acceptable limits.
